B115AFH Arc Fault Circuit Breaker, 120 VAC, 15 A, 22 kA Interrupt, 1 Poles, Thermal Magnetic Trip
| Branch Name | Available |
|---|
A Branch Feeder Type Arc Fault Circuit Interrupter (AFCI) is a device intended to mitigate high current arcing faults in the complete circuit. High current arcing faults occur from line-to-neutral or line-to-ground. These arcing faults are in parallel with the load.
Siemens Arc Fault Circuit Breaker, 120 VAC, 15 A, 22 kA Interrupt, BL Frame, Thermal Magnetic Trip, 1 Pole, 1 Phase, Bolt-On Connection, 14 to 8 AWG, 12 to 8 AWG Wire, Panel Mounting, 40 deg C, 1 in L x 4 in W x 5 in H Dimensions
| Connection Type | : | Bolt-On |
| Dimensions | : | 1 in L x 4 in W x 5 in H |
| Frame | : | BL |
| Mounting Type | : | Panel |
| Phase | : | 1 |
| Temperature Rating | : | 40 deg C |
| Wire Size | : | 14 to 8 AWG, 12 to 8 AWG |
| Voltage Rating | : | 120 VAC |
| Amperage Rating | : | 15 A |
| Interrupt Rating | : | 22 kA |
| Number of Poles | : | 1 |
| Trip Type | : | Thermal Magnetic |
Specification Sheet
