ATM1 Low Voltage Fast Acting Fuse, 1 A, 600 VAC/VDC, 100 kA, Class Midget, Cylindrical Body
| Branch Name | Available |
|---|
Amp-Trap® midget fast acting ATM fuses are rated 600 volts AC and DC, with a 100 kA interrupting rating. These ratings give the ATM a wide range of applications not covered by other midget fuses. In addition, ratings of 30/35, 30/40 and 30/50 A are offered for specific applications such as capacitor protection. These ATM fuses must still be considered 30A fuses because of their dimensions, but are able to withstand much higher inrush currents and tougher duty cycles. (Not for Branch Circuit Protection).
Ferraz Shawmut Amp-Trap® Fast Acting Fuse, Low Voltage, Series: ATM, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 1 A, 600 VAC/VDC, 100 kA Interrupt, Class: Midget, 12 s Response, Ferrule Terminal, Clip Mount, Cylindrical Body, Single Element, Fiber, 13/32 in Dia x 1-1/2 in L Body Size
| Body Size | : | 13/32 in Dia x 1-1/2 in L |
| Element | : | Single |
| Indicating/Non-Indicating | : | Non-Indicating |
| Material | : | Fiber |
| Mounting Type | : | Clip |
| Rejection/Non-Rejection | : | Non-Rejection |
| Response Time | : | 12 s |
| Series | : | ATM |
| Terminal Type | : | Ferrule |
| Type | : | Low Voltage |
| Amperage Rating | : | 1 A |
| Voltage Rating | : | 600 VAC/VDC |
| Interrupt Rating | : | 100 kA |
| Class | : | Midget |
| Body Type | : | Cylindrical |
