Non Stock
TRS450RID TRS-R Low Voltage North American Style Time Delay Power Fuse With Blown Fuse Visual Indication, 450 A, 600 VAC, 200 kA, Class RK5, Cylindrical Body
| Branch Name | Available |
|---|
Tri-Onic® TRS-R current limiting time delay fuses are engineered for overcurrent protection of motors, transformers, service entrance equipment, feeders and branch-circuits. The time delay characteristics of the TRS-R safely handle harmless starting currents and inrush currents associated with todays motors and transformers.
Ferraz Shawmut Tri-Onic® SmartSpot® Power Fuse, Low Voltage North American Style Time Delay, Series: TRS-R, Indicating, Rejection, 450 A, 600 VAC, 200 kA Interrupt, Class: RK5, Blade Terminal, Clip Mount, Cylindrical Body, Polyester, 2.96 in Dia x 13.38 in L Body Size
| Body Size | : | 2.96 in Dia x 13.38 in L |
| Indicating/Non-Indicating | : | Indicating |
| Material | : | Polyester |
| Mounting Type | : | Clip |
| Rejection/Non-Rejection | : | Rejection |
| Series | : | TRS-R |
| Terminal Type | : | Blade |
| Type | : | Low Voltage North American Style Time Delay |
| Amperage Rating | : | 450 A |
| Voltage Rating | : | 600 VAC |
| Interrupt Rating | : | 200 kA |
| Class | : | RK5 |
| Body Type | : | Cylindrical |
Full Engineering Drawing
https://assets.unilogcorp.com/2/ITEM/DOC/Ferraz_Shawmut_TRS450RID_Full_Engineering_Drawing.pdf
Specification Sheet
https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_7008330e0a36a8b2376470611af321a27f87670b4e06f207fb0fef017a18b806.pdf
