HMCP250J5C C Series Type HMCP Motor Circuit Protector, 600 VAC/250 VDC, 250 A, 3 Poles, Magnetic Trip
| Branch Name | Available |
|---|
Designated as Eaton types GMCP and HMCP, the instantaneous only motor circuit protector (MCP). An innovative design of internal components allows higher MCP starter combination interrupting ratings. The MCP is marked to permit proper electrical application within the assigned equipment ratings.
EATON Motor Circuit Protector, Type HMCP, Series: C Series, 600 VAC, 250 VDC, 250 A, J Frame, Magnetic Trip, 875 to 1750 A Trip, 3 Pole, Line/Load Lug Connection, NEMA 5 Enclosure, 4.06 in L x 4.13 in W x 10 in H Dimensions
| Connection Type | : | Line/Load Lug |
| Dimensions | : | 4.06 in L x 4.13 in W x 10 in H |
| Enclosure Type | : | NEMA 5 |
| Frame | : | J |
| Series | : | C Series |
| Trip Range | : | 875 to 1750 A |
| Type | : | Type HMCP |
| Voltage Rating | : | 600 VAC/250 VDC |
| Amperage Rating | : | 250 A |
| Number of Poles | : | 3 |
| Trip Type | : | Magnetic |
