Electrozad

Rees; Cable Operated Switch; Slack Cable; Contact Configuration: 2 NO + 2 NC (Make - Before - Break), (2) NO/NC Each End (Make - Before - Break); Material: High Quality Die-Cast Aluminum Housing; Size: 10.760 IN Length X 3.900 IN Height; Operating Temperature: 0 To +55 DEG C; Environmental Conditions: -40 To +85 DEG C Storage Temperature; Note: Operating Temperatures At 0 DEG C Are Based On The Absence Of Freezing Moisture And Liquids; Normal Potential: 110 - 120 VAC, 220 - 240 VAC, 440 - 480 VAC, 550 - 600 VAC At Power Factor 0.35 Or Less; 115 - 125 VDC, 230 - 250 VDC At Inductive Loads As Specified In Section 125 Of Industrial Control Devices, Controllers And Assemblies, ANSI/NEMA ICS 2-1988; Normal Current: 6, 3, 1.5, 1.2, 2.2, 1.1 AMP; Inrush Current: 60, 30, 15, 12 AMP; Trip Force: 25 LB/End; Operating Force Between 10 Ft Supports: 6 LB; Mechanical Life: 150000 Operations; Wire Size: 14/2 AWG Stranded; Flag End Replaceable: Both; Nema: 4X (Indoor); Color: Yellow Housing; Reset Type: Manual; Finish: Powder Coated Painted Housing; Conduit Openings: (2) 3/4 IN NPT; Ip: 66; Includes: Double Flag Indicator(S) Or Latch Plates; Contact Finish: Gold Plated

• Instruction/Installation Manual https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_b15b3c61708cd11391516fc94ca430555cb721442ea126188ae214dc2f3f3b26.pdf
• Line Drawing https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_a6ad324dc92c5bc6d9ebc5713c94d37b3cb8405e5368216c95ff7cd4c71567c0.jpg
• Specification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_4641a1a7ea658bda15587c791ab135335be938fdf70f34b2f25159cc91bd69bb.pdf
