FWP-25A14F Fast Acting Semiconductor High Speed Fuse With Striker, 25 A, 690/700 VAC, 700/800 VDC, 200/50 kA at 800 VDC Interrupt, Class: AR, Cartridge Body
| Branch Name | Available |
|---|
Edison High Speed Fuse, Fast Acting Semiconductor, Series: FWP, Non-Indicating, Non-Rejection, 25 A, 690/700 VAC, 700/800 VDC, 200/50 kA at 800 VDC Interrupt, Class: AR, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Single Element, Fiberglass, 0.563 in Dia x 2 in L Body Size
| Body Size | : | 0.563 in Dia x 2 in L |
| Element | : | Single |
| Indicating/Non-Indicating | : | Non-Indicating |
| Material | : | Fiberglass |
| Mounting Type | : | Holder |
| Rejection/Non-Rejection | : | Non-Rejection |
| Series | : | FWP |
| Terminal Type | : | Ferrule End |
| Type | : | Fast Acting Semiconductor |
| Amperage Rating | : | 25 A |
| Voltage Rating | : | 690/700 VAC, 700/800 VDC |
| Interrupt Rating | : | 200/50 kA at 800 VDC |
| Class | : | AR |
| Body Type | : | Cartridge |
