Non Stock
Honeywell MICRO SWITCH™ GLAB20A1B GLS General Purpose Industrial Grade Limit Switch, 600 VAC/250 VDC, 10 A, Side Rotary Lever Actuator, 2NO-2NC/DPDT Contact, 2 Poles
| Branch Name | Available |
|---|
Honeywell MICRO SWITCH™ Limit Switch, General Purpose Industrial Grade, Series: GLS, 600 VAC/250 VDC, 10 A, 2NO-2NC/DPDT Contact Configuration, 2 Pole, Snap Action, Side Rotary Lever Actuator, Threaded Entry Connection, NEMA 1/4/12/13/IP67 Enclosure, PG13.5 Size, 15000000 Operating Cycles, -40 to 85 deg C Operating, Die Cast Zinc, Epoxy Coated, Environmental Conditions: 50 g Shock/10 g Vibration
| Action | : | Snap |
| Connection Type | : | Threaded Entry |
| Enclosure Type | : | NEMA 1/4/12/13/IP67 |
| Environmental Conditions | : | 50 g Shock/10 g Vibration |
| Finish | : | Epoxy Coated |
| Material | : | Die Cast Zinc |
| Operating Cycles | : | 15000000 |
| Operating Temperature | : | -40 to 85 deg C |
| Series | : | GLS |
| Size | : | PG13.5 |
| Type | : | General Purpose Industrial Grade |
| Voltage Rating | : | 600 VAC/250 VDC |
| Amperage Rating | : | 10 A |
| Actuator | : | Side Rotary Lever |
| Contact Configuration | : | 2NO-2NC/DPDT |
| Number of Poles | : | 2 |
