Non Stock
HBL5292 2-Circuit Grounding Heavy Duty Standard Straight Blade Combination Duplex Receptacle, 125/250 VAC, 15 A, 2 Poles, 3 Wires, Black
| Branch Name | Available |
|---|
Wiring Device-Kellems Combination Duplex Receptacle, 2-Circuit Grounding Heavy Duty Standard Straight Blade, 125/250 VAC, 15 A, 1-1/2 hp, 3750 W, 1 Phase, 2 Poles, 3 Wires, 14 to 12 AWG Wire, NEMA 5-15R/6-15R, 3.28 in H x 1.5 in W x 0.88 in D, Screw, Threaded, Commercial/Industrial Grade, Wiring Method: Back and Side Wired, Thermoplastic/Composite, Black, Environmental Conditions: -40 to 75 deg C Operating Temperature
| Connection | : | Screw |
| Environmental Conditions | : | -40 to 75 deg C Operating Temperature |
| Grade | : | Commercial/Industrial |
| Horsepower | : | 1-1/2 hp |
| Material | : | Thermoplastic/Composite |
| Mounting | : | Threaded |
| NEMA Rating | : | NEMA 5-15R/6-15R |
| Phase | : | 1 |
| Size | : | 3.28 in H x 1.5 in W x 0.88 in D |
| Type | : | 2-Circuit Grounding Heavy Duty Standard Straight Blade |
| Wattage | : | 3750 W |
| Wire Size | : | 14 to 12 AWG |
| Wiring Method | : | Back and Side Wired |
| Voltage Rating | : | 125/250 VAC |
| Amperage Rating | : | 15 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Black |
Specification Sheet
