Buck-boost transformers are small, 1-phase, dry-type distribution transformers designed and shipped as insulating/isolating transformers. They have a dual voltage primary and a dual voltage secondary. These transformers can be connected for a wide range of voltage combinations. The most common use is to buck (lower) or boost (raise) the supply voltage a small amount, usually 5 to 27%. Buck-boost transformers are in compliance with NEC article 210.9, exception 1, when field connected as an autotransformer.

SolaHD Buck Boost Transformer, Encapsulated, Series: HS19, 120 x 240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA, 60 Hz, 1 Phase, 0.833 A Maximum, Lead Wire, NEMA 3R, 115 deg C, 5 in L x 6 in W x 10 in H

• Low cost, compact size and lightweight
• They are more efficient and cost less than equivalent isolation transformers
• They can handle loads up to 20 times the nameplate rating
• A buck-boost transformer is the ideal solution for changing line voltage by small amounts
• UL listed/NEMA type 3R encapsulated enclosure for indoor and outdoor service
• Electrostatically shielded for quality power on sizes 1 kVA and larger
• 500 to 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications
• Rolled steel enclosure
