64031HPJ HPCJ Open Style Fuse Holder, 1000 VDC, 400 A, Class: J, 6 AWG to 350 kcmil Wire, 1 Pole
| Branch Name | Available |
|---|
MERSEN PV approved class J fuse holders for use with class J photovoltaic fuses. Designed specifically for MERSEN's HP6J series of photovoltaic fuses, these fuse holders are certified for use with 90 deg C temperature rated conductors, an industry first. Fuse holders are available with box connectors, stud connectors or a combination of the two in order to meet various customer requirements. Insulators are either molded glass-filled polycarbonate or phenolic with verified dielectric strength in excess of 2500 VAC. All fuse clips are made of high conductivity tin plated copper.
Ferraz Shawmut Fuse Holder, Open Style, Series: HPCJ, 1000 VDC, 400 A, 1 Pole, Class: J, Box to Box, 6 AWG to 350 kcmil Wire, In-Line Mount, 90 deg C, For Use With: HelioProtection® HP6J Series Photovoltaic Fuses, Polycarbonate/Phenolic, 10 in H x 3 in W
| Connection Type | : | Box to Box |
| Dimensions | : | 10 in H x 3 in W |
| Material | : | Polycarbonate/Phenolic |
| Mounting Type | : | In-Line |
| Series | : | HPCJ |
| Suitable For Use With | : | HelioProtection® HP6J Series Photovoltaic Fuses |
| Temperature Rating | : | 90 deg C |
| Type | : | Open Style |
| Voltage Rating | : | 1000 VDC |
| Amperage Rating | : | 400 A |
| Class | : | J |
| Wire Size | : | 6 AWG to 350 kcmil |
| Number of Poles | : | 1 |
Specification Sheet
