ABB OT60FT3P OT Series Non-Fusible Door Mounted Switch, 600 VAC, 60 A, 20 hp at 240 VAC, 40 hp at 480 VAC, 40 hp at 600 VAC, 3 Poles
| Branch Name | Available |
|---|
Manual switch-disconnectors by ABB are suitable for a wide range of demanding applications ranging from machinery to entire photovoltaic installations. They have been designed to be compact and reliable, offering high performance in even the most demanding environments.
ABB Door Mounted Switch, Non-Fusible, Series: OT Series, 600 VAC, 60 A, 20 hp at 240 VAC, 40 hp at 480 VAC, 40 hp at 600 VAC, 50 Hz Frequency, 3 Pole, 16.5 kA Short Circuit, Pistol Grip Handle Actuator, Door Mounting, -40 to 40 deg C
| Actuator Type | : | Pistol Grip Handle |
| Frequency Rating | : | 50 Hz |
| Mounting Type | : | Door |
| Series | : | OT Series |
| Short Circuit Current Rating | : | 16.5 kA |
| Temperature Rating | : | -40 to 40 deg C |
| Type | : | Non-Fusible |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 60 A |
| Horsepower | : | 20 hp at 240 VAC, 40 hp at 480 VAC, 40 hp at 600 VAC |
| Number of Poles | : | 3 |
