HMCPS030H1C C Series Type HMCP Motor Circuit Protector, 600 VAC/250 VDC, 30 A, 3 Poles, Magnetic Trip
| Branch Name | Available |
|---|
Designated as Eaton types GMCP and HMCP, the instantaneous only motor circuit protector (MCP). An innovative design of internal components allows higher MCP starter combination interrupting ratings. The MCP is marked to permit proper electrical application within the assigned equipment ratings.
EATON Motor Circuit Protector, Type HMCP, Series: C Series, 600 VAC, 250 VDC, 30 A, 50/60 Hz Frequency, F Frame, Magnetic Trip, 90 to 300 A Trip, 3 Pole, Line/Load Lug Connection, NEMA 1 Enclosure, Panel Mounting, 8 x 5 x 5 in Dimensions
| Connection Type | : | Line/Load Lug |
| Dimensions | : | 8 x 5 x 5 in |
| Enclosure Type | : | NEMA 1 |
| Frame | : | F |
| Frequency Rating | : | 50/60 Hz |
| Mounting Type | : | Panel |
| Series | : | C Series |
| Trip Range | : | 90 to 300 A |
| Type | : | Type HMCP |
| Voltage Rating | : | 600 VAC/250 VDC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Trip Type | : | Magnetic |
Catalog
https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_a071634c279370bd5b0e2faab65634acc51e41965c64fd533c388625100b4f1b.pdf
Instruction/Installation Manual
https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_002ec8032b482915d764e884a625e17d55d3c350278ded2b3413118024b7160d.pdf
Specification Sheet
https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_e835081c449fd486922aa8462ba0fe4c1ee0421b865d41177f7f0b5358a78315.pdf
