HP10M25 Type gPV Fast Acting Photovoltaic Fuse, 25 A, 1000 VDC, 10 kA, Class Midget, Cylindrical/Microfuse Body
MERSEN's HP10M photovoltaic (PV) fuse series was developed specifically for the protection of PV string wiring for 1000 VDC industrial rooftop and utility scale photovoltaic systems. Its robust construction makes it ideal for continuous temperature and current cycling withstand adding to system longevity. The 1000 VDC rated HP10M, designed for low minimum breaking capacity capabilities of 1.35 times the fuse rated current value, allows for safe circuit interruption under typical low fault current conditions produced by PV arrays. In addition to the standard ferrule terminal, parts are available with crimp cap terminals for in-line fuse applications. The unique wire crimp terminal (CC option) permits solderless wire-to-fuse connection for overmold encapsulation of fuse and wiring. Protect your off-grid or grid tied PV system from unexpected ground faults and string faults using MERSEN's HelioProtection® fuse line.
Ferraz Shawmut HelioProtection® Photovoltaic Fuse, Type gPV Fast Acting, Series: HP10M, Non-Indicating, Non-Rejection, 25 A, 1000 VDC, 10 kA Interrupt, Class: Midget, 50 kA Short Circuit, Ferrule Terminal, Clip Mount, Cylindrical/Microfuse Body, Single Element, GMG, 0.41 in Dia x 1.5 in L Body Size
| Body Size | : | 0.41 in Dia x 1.5 in L |
| Element | : | Single |
| Indicating/Non-Indicating | : | Non-Indicating |
| Material | : | GMG |
| Mounting Type | : | Clip |
| Rejection/Non-Rejection | : | Non-Rejection |
| Series | : | HP10M |
| Short Circuit Current Rating | : | 50 kA |
| Terminal Type | : | Ferrule |
| Type | : | Type gPV Fast Acting |
| Amperage Rating | : | 25 A |
| Voltage Rating | : | 1000 VDC |
| Interrupt Rating | : | 10 kA |
| Class | : | Midget |
| Body Type | : | Cylindrical/Microfuse |
