EATON Motor Protection Circuit Breakers offer reliable branch circuit and motor protection. Application specific protection eliminates the need for the motor overload relay found in the traditional 3-component starter assembly. Breakers provide complete motor protection when used with a contactor.

EATON Motor Circuit Protector, Type HMCP, Series: C Series, 600 VAC/250 VDC, 100 A, F Frame, Magnetic Trip, 300 to 1000 A Trip, 3 Poles, Line/Load, NEMA 3

• Provides phase loss and phase unbalance protection to prevent severe equipment damage that can occur with a 1-phasing condition
• Thermal memory prevents immediate restart after trip to allow the motor to cool down
• High load alarm LED status indicator provides early warning of potential trip condition

• Catalog https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_597503519f69c092a842217896427baf56fe6ea60183c8de54ed5fe301eea845.PDF
• Instruction/Installation Manual https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_73710aaf81598d108ddc0534f2eb2361db7aa4f30a0c71d72204be492eb9251c.pdf
• Line Drawing https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_eb9f73cd0427b1ed5f5c9f9c700e8e8e7a01186b5f2fe9c4a50a63b4dad73bc3.pdf
• Specification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_cd4180c2b073628dad557f635421d4502af83758000bed243b9d444bc4c48c88.pdf
